Fully Automatic High Speed Double Facer Baker Equipment Intelligent Temperature Control Press Shoes

Industrial Fully Auto Double Facer

Features:

Hot plate within the mature technology from Germany, so that each hot plate has the same temperature in left, medium and right part, temperature deviation does not appear, ensure cardboard to be flatter.

1. Heating plates: multi- plates × 590 mm and polished work surface. Combine the technical of German, Advanced thermal structure for steam, Staggered supply structure,make the hot plates have balance temperature, get the most effective thermal compensation to keep high pressure and high temperature at the high speed.
2. Corrugator Belts are good quality, breathe freely, temperature endurance, aging resistance, good anti-retractility performance. There are two groups of tensing cotton belts device.
3. Auto-rectifying deviation of cotton belt, after checking there is a deviation appeared, the system will calculate the suitable time of rectifying deviation and waiting, start the relevant motor to rectify deviation automatically, decrease effectively the phenomenon of worse agglutinating.
4. Drive wheel is cast by sulfuration rubber, the surface is with V grooves, abrasion endurable, long natural life.
5. Heavy type Dual Universal Joints Drive.
6. Reasonable collocation of steam pipes, the temperature of heating plates can be group controlled. Combine the technical of Germany, control of three sections in high, medium and low voltage Staggered intake and hydrophobic, independent high-pressure intake and hydrophobic structure, ensure high-quality of adhesion and stereotypes the cardboard.

Advantages:

*European advanced energy-saving design, up to 30% energy saving

*Intellgent vector press control, auto adjust according to different type of cardboard production

*High-pressure hot plates of high performance thermal compensation, achieve quick gelatinization

*Automatic temperature control system fit into different cardboard production

*Heavy dual power drive section, Paper entry pretection to avoid danger

The functions:
The main function of a double facer machine (also known as a heating bonding machine) is to bond, heat cure, dry, and cold set single-sided corrugated cardboard and face paper into high-quality three-layer, five layer, or seven layer corrugated cardboard, and then transfer the corrugated cardboard to equipment such as a longitudinal cutting and creasing machine for cutting and processing. The working process of the double-sided machine ensures the structural integrity and strength of the corrugated cardboard, enabling it to meet different packaging needs.

Types of double facer bonding machines
As for the pressure carrier, there are mainly three types of double-sided machines: full roll pressure carrier, pneumatic cover type, and pressure plate type. These different types of double facer machines have their own characteristics and are suitable for producing corrugated cardboard of different specifications and weights. WEST RIVER newly development full pressure double facer machine meeting the different type of corrugated cardboard production.

Selection of double facer machine
Production capacity: Select appropriate specifications and models of double facer machines based on the overall production capacity and speed and expected output of the production line. Ensure that the production capacity of the double facer machine can meet the needs of the production line and avoid insufficient or excessive production heating cause the cardboard quality problems.
Cardboard quality: Consider the quality and performance requirements of the required corrugated cardboard, such as strength, smoothness, waterproof performance, etc. Choose a double facer machine model and configuration that can meet these quality requirements.
Adaptability: Choose a double facermachine that can adapt to the production of corrugated cardboard of different specifications and weights. The double facer machine with adjustable ballast capacity can more flexibly adapt to the production needs of different cardboard.

Thermal conductivity efficiency: The thermal conductivity efficiency of the double facer machine directly affects the bonding effect and energy utilization efficiency of the cardboard. Choose a double facer machine with an efficient heat conduction structure, such as using a unique hot plates structure to improve heat conduction efficiency and save energy. WEST RIVER development most advanced double facer use the newest cylinder type hot-plate, with WEST RIVER intelligent tempeature control system, realize the automatic steam and temperature control according to different production materials, flutes, types of cardboard, speed.. realize most accurate production temperature control!
Stability and reliability: Double facer machine is one of the most important equipment in the corrugated production line, Choose double facer machines with high stability and reliability to reduce the failure rate and downtime during the production process. Consider factors such as manufacturing quality, service life, and after-sales service of the double facer machine.
Cost control: Choose a cost-effective double facer machine while meeting production needs and cardboard quality requirements. Consider factors such as the purchase cost, maintenance cost, and long-term operating cost of the equipment.
