1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System

1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System

  • 1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System
  • 1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System
  • 1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System
  • 1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System
  • 1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System
1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System
Product Details:
Place of Origin: Guangdong
Brand Name: West River
Certification: ISO9001:2000
Model Number: L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 10,000
Packaging Details: Container
Delivery Time: 60 days
Payment Terms: TT, L/C
Supply Ability: 25 sets
Minimum Order Quantity: 1 set
Contact Now
Detailed Product Description
Width: 1200-3300 Speed: 100-350m/min
Steel: Grove Steel(China National Standard) Standard: CE Safety Standard
Structure: Module Structure Name: Corrugated Machine
Raw Material: Craft Paper Material (for Corrugating)

 1/2/3 Layer Span Bridge For Corrugated Cardboard Production Line



CE European Safety Standard Module Design



1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System 0



Introduction to the bridge for the Corrugated Line:
This type of bridge adopts a corrugated structure that resembles waves, giving the bridge a certain degree of curvature and rigidity. The main functions of corrugated bridge include:

Energy saving and weight reduction: The corrugated shape design allows the cable tray to maintain sufficient strength while using less material compared to traditional cable trays, thereby reducing the overall weight and saving material resources.
High space utilization: The corrugated structure design allows the cable tray to have a larger internal space, enabling more efficient use of space for cable routing and improving wiring efficiency.
Excellent mechanical performance: The corrugated structure endows the bridge with good bending and load-bearing capacity, enabling it to withstand large loads and protect the stable wiring of cables and lines.
Corrosion resistance: Corrugated bridge frames are usually made of galvanized or stainless steel materials, which have good corrosion resistance and are suitable for various environmental conditions.
Aesthetics: The wave shape of corrugated bridge frames makes their appearance unique and elegant, suitable for places with high requirements for appearance.

CE safety standard Bridge design.







1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System 1





Correcting the deviation device introduction:
The bridge correction system plays a crucial role in the corrugated cardboard production line. Its main functions are reflected in the following aspects:

Maintain uniform tension throughout the entire line: The correction and tension control system can detect the running position and tightness of the paper web in real time, and adjust the braking force of the raw paper brake according to changes, forming a control loop of "detection → feedback → braking", so that the paper web always maintains appropriate tension on the entire tile line.
Quickly align the width of the entire line: Through the correction system, the position of the cardboard on the production line can be maintained correctly, reducing the loss caused by uneven edges and trimming.
Reduce trimming loss: The correction system can accurately control the edge position of the cardboard, thereby minimizing trimming loss, improving production efficiency and product quality.
In the corrugated cardboard production line, the bridge correction system usually uses a non-destructive pressure wheel correction frame for continuous correction, so that the material surface is not damaged, thereby reducing machine downtime. In addition, the bridge correction system can also operate independently and is suitable for three, five, and seven layer corrugated cardboard production lines. It can also be installed and used on existing old production lines.

WEST RIVER newest correction device use the EL technology from Germany, with most accurate correction function during the high speed corrugated cardboard production.





1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System 2













1/2/3 Layer Span Bridge, Automatic Tension Control, Cardboard Alignment and Web Guiding System 3





Guangdong Zhaoqing WEST RIVER Packaging Machinery Co., Ltd.



As the first professional company engaged in corrugated cardboard and carton machinery in China, it was founded in 1954. Since 1978, it has manufactured the first semi-auto corrugated machinery in China. And from 1999, we began to cooperate with famous Germany company to produce High-speed Fully automatic corrugated cardboard production line for Asian Market. Its vision is to create customized solutions for customers around the world through the continuous efforts of our team and to achieve the sustainable development of Century Old Company.

It can provide a full range of products of corrugated board production line manufacturing. From 2Ply single face, 3Ply single wall, 5Ply double wall to 7Ply to 9Ply heavy package Automatic Corrugated Cardboard Production Line, Fully Automatic Corrugated Cardboard Production Line, And Newest AI control technology, colorful flexo printing, pre-printed cardboard production line development, with more than 60 years of technique accumulation, the company already has a supermarket-scale technique development for the field of corrugated board packaging machinery.



Solutions: Customized Industrial Corrugated Cardbaord and Carton Plant, Free of Consult and Design Solution.



Valid width: 1200mm-3300mm



Design speed: 100M/min-350M/min



Corrugation Type: 2Ply, 3Py, 5Ply, 7Ply



Flute type: A, C, B, E, F, G Flute



Printing: Water Base Flexo Printing



Cotrol System: WEST RIVER INTEGRATE BECKHOFF CONTROL SYSTEM


If you need to consult the corrugated cardboard or carton boxes making equipment, please feel free to contact us. Our team will provide detailed technique consultation and free design solutions for your study and reference.
